Nikon Z mount

35.9 mm x 23.9 mm

CMOS

25.28 million

Image sensor cleaning, Image Dust Off reference data (requires NX Studio)

24.5 million

NEF (RAW): 14 bit; choose from lossless compression, high efficiency (high), and high efficiency options JPEG: JPEG-Baseline compliant with fine (approx. 1 : 4), normal (approx. 1 : 8), or basic (approx. 1 : 16) compression; size-priority and optimal-quality compression available HEIF: Supports fine (approx. 1 : 4), normal (approx. 1 : 8), or basic (approx. 1 : 16) compression; size-priority and optimal-quality compression available NEF (RAW)+JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats NEF (RAW)+HEIF: Single photograph recorded in both NEF (RAW) and HEIF formats

Auto , Standard , Neutral , Vivid , Monochrome , Flat Monochrome , Deep Tone Monochrome , Portrait , Rich Tone Portrait , Landscape , Flat Creative Picture Controls (Dream, Morning, Pop, Sunday, Somber, Dramatic, Silence, Bleached, Melancholic, Pure, Denim, Toy, Sepia, Blue, Red, Pink, Charcoal, Graphite, Binary, Carbon); selected Picture Control can be modified; storage for custom Picture Controls Note: Choice of Picture Controls is restricted to Standard, Monochrome, and Flat when HLG is selected for tone mode during still photography.

DCF 2.0, Exif 2.32, MPEG‑A MIAF

SD , SDHC (UHS-II compliant) , SDXC (UHS-II compliant) , microSD (micro Secure Digital) , microSDHC (UHS-I compliant) , microSDXC (UHS-I compliant)

1 Secure Digital (SD) card and 1 micro Secure Digital (SD) card Either card can be used for overflow or backup storage, for separate storage of NEF (RAW) and JPEG or HEIF pictures, or for storage of duplicate JPEG or HEIF pictures at different sizes and image qualities; pictures can be copied between cards.

Automatically switches between monitor and viewfinder displays

Z mount NIKKOR lenses F mount NIKKOR lenses (mount adapter required; restrictions may apply)

-4 to +2 m-1

Approx. 0.8x (50 mm lens at infinity, -1.0 m-1)

Approx. 100% horizontal and 100% vertical

Electronically-controlled vertical-travel focal-plane mechanical shutter; electronic front-curtain shutter; electronic shutter

Up to 30 fps Continuous low-speed: Approx. 1 to 7 fps Continuous high-speed: Approx. 7.8 fps Continuous high-speed (extended): Approx. 14 fps High-speed frame capture (C30): Approx. 30 fps Maximum frame advance rate as measured by in-house tests.

Single frame , continuous low-speed , continuous high-speed , Continuous high-speed (extended) , high-speed frame capture with Pre-Release Capture , Self-timer

TTL metering using camera image sensor

AUTO: auto, P: programmed auto with flexible program, S: shutter-priority auto, A: aperture-priority auto, M: manual

Luminosity locked at detected value

-3 to +3 EV (-5 to +5 EV when exposure compensation dial is rotated to C) in steps of ¹⁄₃ EV

-4 to +17 EV Figures are for ISO 100 and f/2.0 lens at 20 °C/68 °F

Matrix metering Center-weighted metering: Weight of 75% given to 12 or 8 mm circle in center of frame or weighting can be based on average of entire frame Spot metering: Meters circle with a diameter of approximately 4 mm centered on selected focus point

ISO 100 to 64000 (choose from step sizes of ¹⁄₃ and 1 EV); can also be set to approx. 0.3, 0.7, or 1 EV (ISO 50 equivalent) below ISO 100 or to approx. 0.3, 0.7, 1, or 1.7 EV (ISO 204800 equivalent) above ISO 64000; auto ISO sensitivity control available Note: ISO sensitivity is limited to 400 to 64000 when HLG is selected for tone mode.

Auto, Extra high, High, Normal, Low, and Off

51200

100

273 Number of focus points available in photo mode with single-point AF selected for AF-area mode and FX selected for image area

-10 to +19 EV Measured in photo mode at ISO 100 and a temperature of 20 °C/68 °F using single-servo AF (AF‑S) and a lens with a maximum aperture of f/1.2

Hybrid phase-detection/contrast AF with AF assist

-3 to +1 EV in steps of 1/3 EV

TTL: i‑TTL flash control; i‑TTL balanced fill-flash is used with matrix, center-weighted, and highlight-weighted metering, standard i‑TTL fill-flash with spot metering

Auto (3 types), natural light auto, direct sunlight, cloudy, shade, incandescent, fluorescent (3 types), flash, choose color temperature (2500 to 10,000 K), preset manual (up to 6 values can be stored), all with fine-tuning

Exposure and/or flash , white balance , ADL

Yes

Mode M: Manual selection (ISO 100 to 51200; choose from step sizes of ⅙, ¹⁄₃, and 1 EV); with additional options available equivalent to approximately 0.3, 0.7, 1, or 2 EV (ISO 204800 equivalent) above ISO 51200; auto ISO sensitivity control (ISO 100 to Hi 2.0) available with selectable upper limit Modes P, S, A: Auto ISO sensitivity control (ISO 100 to Hi 2.0) with selectable upper limit AUTO mode: Auto ISO sensitivity control (ISO 100 to 51200) Note: ISO sensitivity is limited to 400 to 51200 when HLG is selected for tone mode.

Built-in stereo or external microphone with attenuator option; sensitivity adjustable

Linear PCM (48 KHz, 24 bit, for videos recorded in MOV format) , AAC (48 KHz, 16 bit, for videos recorded in MP4 format)

MOV , MP4

8 -cm ( 3.2 –in.) diagonal

Approx. 2100 k-dot

Vari-angle TFT touch-sensitive LCD with 170° viewing angle, approximately 100% frame coverage, and color balance and 15-level manual brightness controls

Type C SuperSpeed USB connector; connection to built-in USB ports is recommended Type D HDMI connector Stereo mini-pin jack (3.5 mm diameter; plug-in power supported) Stereo mini-pin jack (3.5 mm diameter)

One EN‑EL15c rechargeable Li-ion battery EN‑EL15b and EN‑EL15a batteries can be used in place of the EN‑EL15c. Note, however, that fewer pictures can be taken on a single charge than with the EN‑EL15c. EH-8P AC adapters can be used to charge EN‑EL15c and EN‑EL15b batteries only.

EH‑7P charging AC adapters (available separately), EH-8P AC adapters (available separately); supplied UC‑E25 USB cable required

Approx. 630 g / 1 lb. 6.3 oz

Approx. 144 x 103 x 49 mm ( 5.7 x 4.1 x 2 in.)

0.635 cm (¹⁄₄ in., ISO 1222)

Yes

Yes

Yes
