DJI Mini 3 Pro RC

Released May 10, 2022

DJI Mini 3 Pro RC

Key specifications
  • Up to 4K60p Video & 48MP Raw Stills
  • Tri-Directional Obstacle Avoidance
  • Up to 34 Minutes of Flight Time
Available Colors
Pricing

Mid Level

Features and Full Specifications

Aircraft

Takeoff Weight

250 g

Dimensions

3.5 x 2.4 x 5.7" / 90.0 x 62.0 x 145.0 mm (Folded) | 14.3 x 2.8 x 9.9" / 362.0 x 70.0 x 251.0 mm (Unfolded)

Max Ascent Speed

11.2 mph / 5 m/s

Max Descent Speed

11.2 mph / 5 m/s

Max Horizontal Speed

35.8 mph / 16 m/s (S Mode) | 22.4 mph / 10 m/s (N Mode) | 13.4 mph / 6 m/s (C Mode)

Camera

Image Sensor

Sensor Type, 1/1.3"-Type CMOS Sensor | Sensor Resolution, Effective: 48 Megapixel

ISO Range

Photo/Video: 100 to 6400 in Manual, Auto Mode

Shutter Speed

Electronic Shutter: 2 to 1/8000 Seconds

Still Photography Modes

DNG / JPEG / Raw 48 MP (8064 x 6048) | 12 MP (4032 x 3024) | 12 MP (4032 x 2268)

Gimbal

Stabilization

3-axis mechanical gimbal (tilt, roll, pan)

Mechanical Range

3 (Pitch, Roll, Yaw) Pitch: -135 to 80° | Roll: -135 to 45° | Yaw: -30 to 30°

Control Accuracy

±0.01°

Vision System

Vision System

Downward, Forward, Backward

Obstacle Sensory Range

1.3 to 82.0' / 0.4 to 25.0 m

Forward Field of View

106° (Horizontal) | 90° (Vertical)

Backward Field of View

58° (Horizontal) | 73° (Vertical)

Operating Environment

Surface with Clear Patterns at >15 lux

Video Transmission

Video Format

3840 x 2160p at 24/25/30/48/50/60 fps (150 Mb/s MOV/MP4 via H.264/AVC, H.265/HEVC) | 2720 x 1530p at 24/25/30/48/50/60 fps (150 Mb/s MOV/MP4 via H.264/AVC, H.265/HEVC) | 1920 x 1080p at 24/25/30/48/50/60/120 fps (150 Mb/s MOV/MP4 via H.264/AVC, H.265/HEVC) |

Max Download Speed

QuickTransfer downloads at up to 30 Mb/s over Wi-Fi

Wi-Fi

Operating Frequency

2.4 GHz (2.400 to 2.483) | 5.8 GHz (5.725 to 5.850)

Transmitter Power (EIRP)

26 dBm (2.4 G) | 26 dBm (5.8 G)

Bluetooth

Protocol

Bluetooth 5.2

Operating Frequency

2.400-2.4835 GHz

Transmitter Power (EIRP)

< 8 dBm

Battery

Capacity

2453 mAh / 18.1 Wh

Weight

2.8 oz / 80.5 g

Battery Configuration

2 S / 7.38 V

Model

Intelligent Flight Battery

Type

Lithium-Ion Polymer (LiPo)

Maximum Charging Power

37 W

Charger

Recommended Charger

DJI 3OW USB-C Charger

Charging Time

1 hour and 4 minutes

DJI RC-N3 Remote Controller

Operating Temperature

DJI 3OW USB-C Charger

Charging Temperature

5° to 40° C (41° to 104° F)

Charging Time

1 hour and 4 minutes

Charging Type

Charge three batteries in sequence

Battery Capacity

2453 mAh
