DJI Mavic Air 2
Released April 27, 2020
DJI Mavic Air 2
Key specifications
- 10km 1080p Video Transmission
- 8K Hyperlapse
- 34-Min Max Flight Time
Available Colors
Mid Level
Features and Full Specifications
Aircraft
570g
3.8 x 3.3 x 7.1" / 97.0 x 84.0 x 180.0 mm (Folded) | 10.0 x 3.0 x 7.2" / 253.0 x 77.0 x 183.0 mm (Unfolded)
4 m/s (S Mode) | 4 m/s (N Mode)
3 m/s (S Mode) | 3 m/s (N Mode)
19 m/s (S Mode) | 12 m/s (N Mode) | 5 m/s (T Mode)
Camera
1/2″ CMOS Effective Pixels: 12 MP and 48 MP
FOV: 84° Equivalent Focal Length: 24 mm | Aperture: f/2.8 | Focus Range: 1 m to ∞ |
Video: 100-6400 | Photo (12 MP): 100-3200 (Auto) 100-6400 (Manual) | Photo (48 MP): 100-1600 (Auto) 100-3200 (Manual) |
8-1/8000s
48MP: 8000x6000 | 12MP: 4000X3000
Single: 12 MP/48 MP | Burst: 12 MP, 3/5/7 frames | Automatic Exposure Bracketing (AEB): 12 MP, 3/5 Frames at 0.7EV Step | Timed: 12 MP 2/3/5/7/10/15/20/30/60 seconds | SmartPhoto: 12 MP | HDR Panorama: Vertical (3x1): 3328x8000 pixels (WxH) | Wide (3x3): 8000x6144 pixels (WxH) | 180° Panorama (3x7): 8192x3500 pixels (WxH) | Sphere (3x8+1): 8192x4096 pixels (WxH) |
Gimbal
3-axis (tilt, roll, pan)
Tilt: - 135° to +45° | Roll: -45° to +45° | Pan: -100° to + 100° |
Tilt: -90° to 0° (default setting) | -90° to +24° (extended setting) | Pan: -80° to +80° |
100°/s
±0.01°
Sensing System
Precision Measurement Range: 0.35-22.0 m | Detection Range: 0.35-44 m | Effective Sensing Speed: ≤12 m/s | FOV: 71° (horizontal), 56° (vertical) |
Precision Measurement Range: 0.37-23.6 m | Detection Range: 0.37-47.2 m | Effective Sensing Speed: ≤12 m/s | FOV: 44° (horizontal), 57° (vertical)
Infrared Sensor Measurement Range: 0.1-8 m | Hovering Range: 0.5-30 m | Vision Sensor Hovering Range: 0.5-60 m
Non-reflective, discernible surfaces with diffuse reflectivity of >20%; Adequate lighting of lux > 15
Video Transmission
OcuSync 2.0
720p@30fps/1080p@30fps
2.4 GHz (2.400 to 2.484) | 5.8 GHz (5.725 to 5.850)
Wi-Fi
802.11 a/b/g/n/ac
2.400-2.4835 GHz | 5.725-5.850 GHz
2.400-2.4835 GHz FCC: ≤26 dBm CE: ≤20 dBm SRRC: ≤20 dBm MIC: ≤20 dBm | 5.725-5.850 GHz FCC: ≤26 dBm CE: ≤14 dBm SRRC: ≤26 dBm
Battery
3500 mAh
198 g
11.55 V
13.2 V
LiPo 3S
40.42 Wh
Remote Controller / Transmitter
2.4 GHz (2.400 to 2.484) | 5.8 GHz (5.725 to 5.850)
32 to 104°F / 0 to 40°C
6.21 Miles / 10 km at 2.4 G
2.4 G: 26 dBm | 5.8 G: 26 dBm
