Canon EOS R6 Mark II (RF24-105mm f/4-7.1 IS STM)

Released November 2, 2022

Canon EOS R6 Mark II (RF24-105mm f/4-7.1 IS STM)

Key specifications
  • Approx. 24.2MP full-frame CMOS sensor
  • 6K RAW HDMI out, 4K 60p (6K Oversampling) & FHD 180p
  • Up to 40 fps & up to 8 stops image stabilisation
Available Colors
Pricing

High Level

Features and Full Specifications

SPECIFICATIONS

Image sensor

24.2 megapixels, full-frame (36.0 × 24.0 mm) CMOS sensor

Image processor

DIGIC X

Lens mount

Canon RF mount

Compatible lenses

Canon RF and RF-S lenses, Canon EF and EF-S lenses (EF-EOS R mount adapter required)

RECORDING SYSTEM

Recording media

2 memory cards, • 2 x SD, SDHC, SDXC memory card (UHS-II compatible)

Pixels recorded

RAW/C-RAW, HEIF, JPEG Large: Approx. 24.2 MP (6000 x 4000), HEIF, JPEG Medium: Approx. 10.6 MP (3984 x 2656), HEIF, JPEG Small 1: Approx. 5.9 MP (2976 x 1984), HEIF, JPEG Small 2: Approx. 3.8 MP (2400 x 1600)

AUTOFOCUS

Focus method

Dual Pixel CMOS AF II

AF method

Spot AF, 1-point AF, Expand AF area (above/below/left/right/around), Flexible Zone AF 1 / 2 / 3, Whole area AF

Available AF point positions

Stills: Max. 4897 positions (83 x 59), Movies: Max. 4067 positions (83 x 49)

Available AF areas when automatically selected

Stills: Max. 1053 zones (39 x 27), Movies: Max. 1053 zones (39 x 27)

Subject Detection AF

EOS iTR AF X (intelligent Tracking & Recognition) – Automatic / Human priority / Animal priority / Vehicle priority

Focusing brightness range

Stills: EV -6.5 to 21, Movies: EV -4.0 to 21 (4K), EV -4.5 to 21 (Full HD)

EXPOSURE CONTROL

Metering sensor

384 zones (24 x 16) metering using image sensor output signals

Metering mode

Stills: Evaluative metering, Partial metering, Spot metering, Centre-weighted average Movies: Evaluative metering (when faces are detected), Center-weighted average (when no faces are detected, when set to Canon Log 3)

Metering brightness range

Stills: EV -3 to 20 (at room temperature, ISO 100), Movies: EV -1 to 20 (at room temperature, ISO 100)

Shooting mode

Stills: Scene Intelligent Mode, Hybrid Auto, Special Scene Mode, Creative Filters, Fv, P, Tv, Av, Manual, Long Bulb Exposure*, Custom Shooting Modes (C1 / C2 / C3). Movies: Scene Intelligent Mode, Special Scene Mode (HDR Movie), Creative Filters, P, Tv, Av, Manual, Custom Shooting Modes (C1 / C2 / C3).

ISO speed (recommended exposure index)

Stills: ISO 100-102400*, expandable to L (ISO 50), H (ISO 204800) (ISO 200-102400 with Highlight tone priority set) Movies: ISO 100-25600* expandable to H (ISO 204800) (ISO 200-12800 with Highlight tone priority set)

Exposure compensation

± 3 stops in 1 / 3 or 1 / 2-stop increments, AEB ± 3 stops or 1 / 2-stop increments

HDR PQ

Recording format

Stills: HEIF, Movies: MP4

Bit depth

10-bit

Colour sampling

YCbCr 4:2:2

HDR standards

Rec. ITU-R BT.2100 (PQ)

SHUTTER

Shutter mode

Mechanical, Electronic 1st curtain, Electronic

Shutter Speed

Mechanical / Electronic 1st curtain : 1 / 8000 secs. - 30 secs. Electronic shutter: 1 / 16000 secs. - 30 secs. Movie recording: 1 / 8000 secs. - 1 / 60 secs.

X-sync

Mechanical shutter: 1 / 200 secs. Electronic 1st-curtain: 1 / 250 secs.

DRIVE SYSTEM

High-speed continuous shooting

Mechanical / Electronic 1st curtain shutter: Max. approx. 12 shots/sec. Electronic shutter: Max. approx. 40 shots/sec.

MOVIE RECORDING

Movie recording size

4K UHD (3840 x 2160) (Uncropped / Cropped), Full HD (1920 x 1080) (Uncropped / Cropped)

HDMI RAW output (External Recording*)

6K RAW (6000 x 3374), 3.7K RAW (3744 x 2106), ProRes RAW format

Frame rate

6K RAW: 59.94p / 29.97p / 25.00p / 50.00p / 23.98p 4K UHD/4K UHD Crop: 59.94p / 29.97p / 25.00p / 50.00p / 23.98p 4K UHD time-lapse: 29.97p / 25.00p 3.7K RAW: 59.94p / 29.97p / 25.00p / 50.00p / 23.98p High frame rate movie HD: 179.82p / 119.88p / 150.00p / 100.00p Full HD: 59.94p / 50.00p / 29.97p / 25.00p / 23.98p Time-lapse Full HD: 29.97p / 25.00p HDR movie: 29.97p / 25.00p Creative filters Full HD: 29.97p / 25.00p / 23.98p

Canon Log

Canon Log 3

SCREEN

Screen type

Vari-angle, TFT colour, LCD touch screen

Screen size and dots

Approx. 7.62 cm / 3.0 in. (3:2) with approx. 1.62 million dots

VIEWFINDER

Viewfinder type

OLED colour electronic viewfinder

Viewfinder size and dots

Approx. 1.27 cm / 0.5 in. (3:2) with approx. 3.69 million dots

Wi-Fi and Bluetooth

Standards compliance

IEEE 802.11 ac/a/b/g/n equivalent

Transmission frequency (Centre frequency)

5GHz band (5180-5825 MHz)*, 2.4GHz band (2412-2462 MHz)*

Compatible devices

Smart devices, computer and FTP server

Bluetooth

Bluetooth Ver. 5.0

INTERFACE

Digital terminal

SuperSpeed Plus USB (USB 3.2 Gen 2) equivalent, USB Type-C

HDMI output terminal

Type D, supports 4K 60p output

External microphone input & headphone terminal

Available

Remote control

Supports Wireless Remote Control BR-E1 (Bluetooth)

POWER

Battery

LP-E6NH / LP-E6N / LP-E6

DIMENSIONS AND WEIGHT

Dimensions (W x H x D) (CIPA compliant)

Approx. 138.4 x 98.4 x 88.4 mm

Weight (CIPA compliant

Approx. 670g / 23.63 oz. (including battery and memory card)
