Approx. 24.1 megapixels, full-frame (approx. 36.0 × 24.0 mm) back-illuminated stacked CMOS sensor

DIGIC X

Canon RF mount

Canon RF lens, Mount Adapter EF-EOS R: Canon EF or EF-S lenses (excluding EF-M lenses)

2 memory cards • 1x CFexpress memory card (Type-B compatible) • 1x SD, SDHC or SDXC memory card (UHS-II compatible)

Available

Available (Up to 5.5 stops)

Available (Up to 8.0 stops)

HEIF, JPEG Large: 24 megapixels (6000 × 4000), HEIF, JPEG Medium: Approx. 10.6 megapixels (3984 × 2656), HEIF, JPEG Small 1: Approx. 5.9 megapixels (2976 × 1984), HEIF, JPEG Small 2: Approx. 3.8 megapixels (2400 × 1600), RAW / C-RAW: 24 megapixels (6000 × 4000)

Dual Pixel CMOS AF II

One-Shot AF, Servo AF (default)

Spot AF, 1-point AF, Expand AF area (above / below / left / right or around), Flexible Zone AF 1 / 2 / 3, Whole area AF

Up to 1053 AF frame zones

Available

Line-of-sight sensor (approx.): 7560 pixels, Number of calibration data: 6

Normal: 100 to 102400, Expansion for lower speeds (ISO equivalent): L: 50, Expansion for faster speeds (max. ISO equivalent): H: 204800

Normal: 100 to 25600, Expansion for faster speeds (max. ISO equivalent): H1: 102400

Still photos (at 23°C / 73°F, ISO 100): EV –3 to 20, Movies (at 23°C / 73°F, ISO 100, center-weighted average metering): EV –1 to 20

Available

Available

Compatible with all lenses

HDR PQ (Stills / Movie)

10-bit

YCbCr 4:2:2

Rec. ITU-R BT.2100 (PQ)

Mechanical, Electronic 1st-curtain, Electronic

Available

Available

Mechanical shutter: 1/8000 to 30, Electronic 1st-curtain: 1/8000 to 30, Electronic shutter: 1/64000, 1/32000, 1/16000, 1/12800, 1/10000, 1/8000 to 30

Mechanical shutter: X-sync at 1/200 sec. Electronic 1st-curtain X-sync at 1/250 sec. Electronic shutter X-sync at 1/180 sec.

Simultaneous recording of video (MP4) onto both CFexpress card and SD card is possible. When a RAW movie is recorded on a CFexpress card, movie data in 4K MP4 can be simultaneously recorded on an SD card.

59.94 fps / 29.97 fps / 24.00 fps / 23.98 fps (NTSC), 50.00 fps / 25.00 fps / 24.00 fps (PAL)

119.88 fps / 59.94 fps / 29.97 fps / 24.00 fps / 23.98 fps (NTSC), 100.00 fps / 50.00 fps / 25.00 fps / 24.00 fps (PAL)

119.88 fps / 59.94 fps / 29.97 fps / 24.00 fps / 23.98 fps (NTSC), 100.00 fps / 50.00 fps / 25.00 fps / 24.00 fps (PAL)

119.88 fps / 59.94 fps / 29.97 fps / 24.00 fps / 23.98 fps (NTSC), 100.00 fps / 50.00 fps / 25.00 fps / 24.00 fps (PAL)

RAW: Linear PCM, ALL-I / IPB (Standard): AAC / Linear PCM*, IPB (Light): AAC

Newly developed 5.67 million-dot (approx.) high-speed viewfinder

119.88 fps

100%

0.76x

23mm

3.2-inch (3:2) Vari-angle, TFT colour, LCD Touchscreen, with approx. 4.15 million-dot

128 x 128 dots, reflective memory LCD

IEEE 802.11b/g/n/a/ac

Ver.5.0 (BLE)

SuperSpeed Plus USB (USB 3.2 Gen 2) equivalent

1000BASE-T / 100BASE-TX / 10BASE-T

Available

NEW

USB* Type-C

Type D

Available

Available

1x LP-E19

Normal movies 6 hr. 00 min. 00 sec, High frame rate 1 hr. 30 min. 00 sec.

Approx. 150.0 x 142.6 x 87.2 mm

Approx. 1015g, (including battery and memory cards)
