Steam Deck

Steam Deck
Steam Deck
Key specifications
- Zen 2 + RDNA 2 powerhouse
- 16 GB LPDDR5 on-board RAM
- Optically bonded IPS LCD
Available Colors
Mid Level
Features and Full Specifications
Processor
Zen 2 4c/8t, 2.4-3.5GHz (up to 448 GFlops FP32)
8 RDNA 2 CUs, 1.0-1.6GHz (up to 1.6 TFlops FP32) APU power: 4-15W
16 GB LPDDR5 on-board RAM (5500 MT/s quad 32-bit channels)
64 GB eMMC (PCIe Gen 2 x1), 256 GB NVMe SSD (PCIe Gen 3 x4 or PCIe Gen 3 x2*), 512 GB high-speed NVMe SSD (PCIe Gen 3 x4 or PCIe Gen 3 x2*)
Controls and Input
A B X Y buttons, D-pad, L & R analog triggers L & R bumpers View & Menu buttons 4 x assignable grip buttons
2 x full-size analog sticks with capacitive touch
HD haptics
2 x 32.5mm square trackpads with haptic feedback, 55% better latency compared to Steam Controller, Pressure-sensitivity for configurable click strength
6-Axis IMU
Display
1280 x 800px (16:10 aspect ratio)
Optically bonded IPS LCD for enhanced readability
7" diagonal
400 nits typical
60Hz
Ambient light sensor
Connectivity
Bluetooth 5.0 (support for controllers, accessories and audio)
Dual-band Wi-Fi radio, 2.4GHz and 5GHz, 2 x 2 MIMO, IEEE 802.11a/b/g/n/ac
Audio
Stereo with embedded DSP for an immersive listening experience
Dual microphone array
3.5mm stereo headphone / headset jack
Multichannel audio via DisplayPort over USB-C, standard USB-C, or Bluetooth 5.0
Power
45W USB Type-C PD3.0 power supply
40Whr battery. 2 - 8 hours of gameplay
Expansion
UHS-I supports SD, SDXC and SDHC
USB-C with DisplayPort 1.4 Alt-mode support; up to 8K @60Hz or 4K @120Hz, USB 3.2 Gen 2y
Dimensions
Size: 298mm x 117mm x 49mm, Weight : Approx. 669 grams
Software
SteamOS 3.0 (Arch-based)
KDE Plasma
