Dell OptiPlex 7090 Ultra Desktop

Released January 15, 2022

Dell OptiPlex 7090 Ultra Desktop

Key specifications
  • Intel® Iris® Xe graphics
  • 11th Gen Intel® Core™ processors
  • Dual storage with up to a 2TB SSD and up to a 2TB SATA hard drive.
  • up to 64GB 3200MHz DDR4 RAM
Available Colors
Pricing

High Level

Features and Full Specifications

Platform

Processor

11th Generation Intel® Core™ i3-1115G4 (6 MB Cache, 2 Cores, 4 Threads, 3.0 GHz to 4.1 GHz, 28 W), 11th Generation Intel® Core™ i5-1145G7 (vPro®, 8 MB Cache, 4 Cores, 8 Threads, 2.6 GHz to 4.4 GHz, 28 W), 11th Generation Intel® Core™ i7-1185G7 (vPro®, 12 MB Cache, 4 Cores, 8 Threads, 3.0 GHz to 4.8 GHz, 28 W)

Operating System

Windows 11 Pro, 64-bit, Windows 11 Home, 64-bit, Windows 11 Pro Education, 64-bit, Windows 11 CMIT Government Edition (CMGE) v10, Windows 11 IoT Enterprise 2019, LTSC (OEM only), Windows 10 Pro (Includes free Upgrade to Windows 11 Pro), Ubuntu® 20.04

Video Card

Intel® UHD Graphics (with 11th Generation Intel® Core™ i3 processor), Intel® Iris®Xe Graphics (with 11th Generation Intel® Core™ i5/i7 processors)

Memory

Memory

4 GB, 1 x 4 GB, DDR4, 3200 MHz, 8 GB, 1 x 8 GB, DDR4, 3200 MHz, 8 GB, 2 x 4 GB DDR4, 3200 MHz, 16 GB, 1 x 16 GB, DDR4, 3200 MHz, 16 GB, 2 x 8 GB, DDR4, 3200 MHz, 32 GB, 1 x 32 GB, DDR4, 3200 MHz, 32 GB, 2 x 16 GB, DDR4, 3200 MHz, 64 GB, 2 x 32 GB, DDR4, 3200 MHz

Storage

2.5-inch, 1 TB, 5400 RPM, SATA, HDD, 2.5-inch, 2 TB, 5400 RPM, SATA, HDD, 2.5-inch, 500 GB, 7200 RPM, SATA, HDD, Self-Encrypting, Opal 2.0, FIPS, 2.5-inch, 500 GB, 7200 RPM, SATA, HDD, 2.5-inch, 1 TB, 7200 RPM, SATA, HDD, M.2 2230, 128 GB, Gen 3 PCIe x4, NVMe, Class 35 SSD, M.2 2230, 256 GB, Gen 3 PCIe x4, NVMe, Class 35 SSD, M.2 2230, 512 GB, Gen 3 PCIe x4 NVMe, Class 35 SSD, M.2 2230, 256 GB, Gen 3 PCIe x4 NVMe, Class 35 SSD, self-encrypting drive, M.2 2280, 256 GB, Gen 3 PCIe x4, NVMe, Class 40 SSD, M.2 2280, 512 GB, Gen 3 PCIe x4, NVMe, Class 40 SSD, M.2 2280, 1 TB, Gen 3 PCIe x4, NVMe, Class 40 SSD, M.2 2280, 2 TB, Gen 3 PCIe x4, NVMe, Class 40 SSD, M.2 2280, 256 GB, Gen 3 PCle x4 NVMe, Class 40 SSD, self-encrypting drive, M.2 2280, 512 GB, Gen 3 PCIe x4 NVMe, Class 40 SSD, self-encrypting drive, M.2 2280, 1 TB, Gen 3 PCIe x4 NVMe, Class 40 SSD, self-encrypting drive, Intel® Optane™ Memory H20 with Solid State Storage, 512 GB, M.2 2280, PCIe NVMe Gen3 x4, 32 GB eMMC – supported on Ubuntu only, 64 GB eMMC – supported on Ubuntu only

Ports

Side

1 USB 3.2 Gen 2 Type-A port with PowerShare, 1 USB 4™ Type-C® with DisplayPort Alt Mode/Thunderbolt™ 4.0, 1 Headset/Universal Audio Jack

Rear

2 USB 3.2 Gen 2 Type-A with SmartPower On, 1 USB 3.2 Gen 2 Type-C port with DisplayPort Alt Mode/Power Delivery, 1 RJ45 Network Connector, 1 4.50 mm x 2.90 mm DC-in port, 1 DisplayPort 1.4++ HBR2 port

Slots

1 Security screw hole to secure cover, 1 Kensington lock slot

Dimensions

Size

Height: 256.2 mm (10.09"), Width: 96.1 mm (3.78"), Depth: 19.7 mm (0.78"), Depth with HDD: 27.7 mm (1.09")

Weight

0.65 kg (1.43 lb)

Others

Wireless*

Qualcomm QCA61x4A, 2x2, 802.11ac, MU-MIMO, Bluetooth® wireless card, Intel® Wi-Fi 6 AX201, 2x2, 802.11ax, Bluetooth® wireless card

Power

E4 90 W, 4.5 mm

Keyboard

Dell Wireless Keyboard and Mouse - KM5221W, Dell KB216 Multimedia Keyboard, Dell KB813 Smartcard Keyboard, Dell KM636 Wireless Keyboard and Mouse Combo, Dell KB522 Multimedia Wired Keyboard
