IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, WiFi 4 (802.11n), WiFi 5 (802.11ac), WiFi 6 (802.11ax), IPv4, IPv6

AX3000 ultimate AX performance : 2402 Mbps+ 574 Mbps

802.11a : up to 54 Mbps, 802.11b : up to 11 Mbps, 802.11g : up to 54 Mbps, WiFi 4 (802.11n) : up to 300 Mbps, WiFi 5 (802.11ac) : up to 867 Mbps, WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps, WiFi 6 (802.11ax) (5GHz) : up to 2402 Mbps

Internal dual-band antenna x 2

2.4GHz 2x2, 5GHz 2x2

MIMO technology

128 MB Flash, 512 MB RAM

2.4 G Hz / 5 GHz

RJ45 for Gigabits BaseT for WAN/LAN x 1, RJ45 for Gigabits BaseT for LAN x1

WPS Button, Reset Button

Power x 1

AC Input : 110V~240V(50~60Hz), DC Output : 12 V with max. 1.5 A current

307 g

• Primary AiMesh Router • AiMesh Node

"Allow you to block access to unwanted websites and apps." Parental Control - Safe Browsing, Customized Internet Schedule

WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise, WPS support, WPS, Let's Encrypt, SSH, Security Scan, Firewall • Maximum Firewall Keyword Filter : 64 • Maximum Firewall Network Service Filter : 32 • Maximum Firewall URL Filter : 64

• Malicious Site Blocking • Infected Device Prevention and Blocking

UTF-8 SSID

DHCP Server, IGMP Snooping, IPTV, Manually Assign IP Address, Wake on LAN (WOL)
