DJI Focus Pro

Released April 9, 2024

DJI Focus Pro

Key specifications
  • 20-Meter Subject Focusing, 76,800 Ranging Points
  • Built-in Camera, Enhanced AI Recognition Algorithms
  • AMF Mode, Human-Machine Collaborative Focus Control
Available Colors
Pricing

Mid Level

Features and Full Specifications

LiDAR

Accessory Port

Cold Shoe, 1/4"-20 Threaded Hole, USB-C Firmware Update Port (Power/USB), USB-C Data Port (Power/CVBS/CAN)

Image Sensor

Resolution: 1920×1440, FOV: ‌57.4° (horizontal), 44.6° (vertical), 70.1° (diagonal), Frame Rate: 30fps, Equivalent Focal Length: 30 mm

ToF Sensor

Ranging Points: 76,800 Sensing Range: 0.5-20 m. FOV: Wide-Angle Mode: 65° (horizontal), 40° (vertical), 76.1° (diagonal), Telephoto Mode: 20° (horizontal), 20° (vertical), 28.3° (diagonal), Frame Rate: 30fps, Equivalent Focal Length: 30 mm (wide-angle mode), Ranging Accuracy: ±1% to 3% (affected by the distance)

Electrical Properties

‌Power Consumption: Average approx. 6.3 W, max 6.8 W. Input Voltage: 6.6-17.2 V

Mechanical Properties

Main Body Dimensions: Approx. 68×25×57 mm (L×W×H), Weight: Approx. 140 g (0.31 lbs)

Mounting Method and Position

Can be mounted directly via cold shoe or using the 1/4" threaded hole

Grip

Operating Frequency

2.400-2.4835 GHz

Bluetooth Transmitter Power

< 8 dBm

Mechanical Properties

Main Body Dimensions: Approx. 59×73×162 mm (L×W×H), Main Body Weight: Approx. 482 g (1.06 lbs)

Screen

1.8-inch full-color touchscreen

Battery and Charging

Battery Model: BHX711-3000-7.2V, Charging Power: Supports 18W PD fast charging,

Port

USB-C Port (DJI Focus Pro LiDAR), USB-C Port (DJI Focus Pro Motor), USB-C Port (Camera Control Port), USB-C Port (Battery Charging Port)

Hand Unit

Operating Frequency

2.400-2.4835 GHz

2.4GHz Transmitter Power (EIRP)

‌< 20 dBm (CE/SRRC/MIC), < 26 dBm (FCC)

2.4GHz Transmission Distance

160 m, 100 m

Mechanical Properties

‌Dimensions: Approx. 128×87×87 mm (L×W×H), Weight: Approx. 555 g (1.22 lbs) (without battery)

Battery

Model: NP-F550, Input: 6.3-8.4 V, Dimensions: 71×38.6×21.1 mm (L×W×H)

Screen

1.09-inch full-color touchscreen

Motor

2.4GHz Transmitter Power (EIRP)

‌< 20 dBm (CE/SRRC/MIC), < 26 dBm (FCC)

2.4GHz Transmission Distance

160 m, 100 m

Mechanical Properties

‌Dimensions: Approx. 100×61×34 mm (L×W×H), ‌Weight: Approx. 123 g (0.27 lbs), Rod Diameter: 15 mm, Output Gear Teeth: 30, Output Gear Module: 0.8

Performance

Max Torque: 0.6 N·m (8 V), Max Speed: 300 rpm (8 V)

Power Supply Voltage

6.6-17.2 V
