IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, WiFi 4 (802.11n), WiFi 5 (802.11ac), WiFi 6 (802.11ax), IPv4, IPv6

AX6000 ultimate AX performance : 1148+4804 Mbps

802.11a : up to 54 Mbps, 802.11b : up to 11 Mbps, 802.11g : up to 54 Mbps, WiFi 6 (802.11ax) (2.4GHz) : up to 1148 Mbps, WiFi 6 (802.11ax) (5GHz) : up to 4804 Mbps

External antenna x 6

2.4GHz 4x4, 5GHz 4x4

OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80/160 MHz bandwidth

2.0 GHz quad-core processor

256 MB Flash, 512 MB RAM

2.4GHz / 5GHz

Wireless router mode, Access point mode, Media bridge mode

RJ45 for 2.5 Gigabits BaseT for WAN x 1, RJ45 for 2.5 Gigabits BaseT for LAN x 1, RJ45 for Gigabits BaseT for LAN x 4, USB 3.2 Gen 1 x 1,

WPS Button, Reset Button, Power Button

Power x 1, WiFi x 1, 1G LAN x 4, 2.5G WAN x 1, 2.5G LAN x 1

AC Input : 100V~240V (50~60Hz), DC Output : 12 V with max. 2.5 A current

696g

301.02 x 174 x 216 mm

• Primary AiMesh Router • AiMesh Node

Game Boost / Acceleration, Mobile Game Mode

"Allow you to block access to unwanted websites and apps." Safe Browsing, Customized Internet Schedule

AiProtection, WPS support, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise, WPS, Let's Encrypt, DNS-over-TLS, SSH, Security Scan, Firewall, • Maximum Firewall Keyword Filter : 64 • Maximum Firewall Network Service Filter : 32 • Maximum Firewall URL Filter : 64

• Router Security Assessment, • Malicious Site Blocking, • Two-Way IPS, • Infected Device Prevention and Blocking

UTF-8 SSID, WiFi MAC Address Filter, • Maximum MAC Filters : 64, Wireless Scheduler, Airtime Fairness, RADIUS Client, Universal Beamforming, Explicit Beamforming
