MSI MAG FORGE 320R AIRFLOW
Released December 17, 2023
MAG FORGE 320R AIRFLOW
Key specifications
- Built-in ARGB fans and control board
- Tempered Glass Side Panel displays RGB lighting effects
- Supports up to 360 mm AIO liquid cooler and large 40 series GPU.
Available Colors
Pricing
Entry Level
Features and Full Specifications
Product
DIMENSIONS (DXWXH)
472.5 x 210 x 498 mm / 18.60 x 8.26 x 19.60 inches
NET WEIGHT
7.05 kg / 15.54lbs
GROSS WEIGHT
8.35 kg / 18.41lbs
MAXIMUM GPU LENGTH
390 mm / 15.35 inches
MAXIMUM CPU COOLER HEIGHT
160 mm / 6.29 inches
MAXIMUM PSU LENGTH
200 mm / 7.87 inches (without 2.5"/3.5" HDD tray installation)
Fan
FAN SIZE SUPPORT
Front: 3 x 120 mm / 2 x 140 mm, , Top: 3 x 120 mm / 2 x 140 mm, Rear: 1 x 120 mm, Side: 2 x 120 mm, PSU Shroud: 2 x 120 mm
PRE-INSTALLED FAN SIZE
Front: 3 x 120 mm Rear: 1 x 120 mm
PRE-INSTALLED FAN TYPE
Front: 3 x ARGB Fan, Rear: 1 x ARGB Fan
Other Specs
MOTHERBOARD FORM FACTOR SUPPORT
ATX / Micro-ATX / Mini-ITX
I/O PORTS
2 x USB 3.2 Gen 1 Type-A 1 x Audio-out 1 x Mic-in 1 x LED Switch
DRIVE MOUNT SUPPORT
1 x 2.5" 2 x 2.5" / 3.5"
EXPANSION SLOTS
7
POWER SUPPLY SUPPORT
ATX
RADIATOR SIZE SUPPORT
Front: 120 / 140 / 240 mm, Top: 120 / 240 / 280 / 360 mm, Rear: 120 mm
