AMD Ryzen™ 9-5900X Processor

AMD® X570 Chipset

NVIDIA® GeForce® RTX 3080 10GB : DisplayPort 1.4a *3, HDMI 2.1 *2

32GB DDR4-3600(XMP)

6 x SATA 6.0Gb/s ports

1TB M.2 PCIe® 4.0 SSD, 2TB M.2 NVMe™ PCIe® 3.0 SSD

1x USB 3.2 Gen 1 Type-C, 2x USB 3.2 Gen 1 Type-A, 1x Headphone, 1x Mic

1 x USB Type-C® port, with USB 3.2 Gen2, 3 x USB 3.2 Gen 2 Type-A ports (red), 2 x USB 3.2 Gen 1 Type-A, 4 x USB 2.0 Type-A, 2 x SMA antenna connectors (2T2R), 2 x HDMI port (from Graphics card), 3x Displayport (from Graphics card), 2 x RJ-45 port, 1 x optical S/PDIF Out connector, 5 x audio jacks, 1 x Q-Flash Plus button, 1 x Clear CMOS button

1 x PCI Express x16 slot, running at PCIeX4, 1 x PCI Express x1 slot, 1 x M.2 PCIe Gen4 x4 connector for SSD (Back), 4 x DDR4 U-DIMM Slots (2 occupied)

1 x Realtek 2.5GbE RJ-45 (Support 2.5G/1G/100M), 1 x Intel® 1GbE RJ-45 (Support 10/100/1000M)

58L

223*521*500 mm

ATX

3 x 2.5", 2 x 3.5"

Support 2/4/5/7.1 Channel, ESS Sabre HiFi

360mm Liquid Cooler

Transparent side panel

Wi-Fi 6 (802.11ax) with 2T2R Antenna, BLUETOOTH 5.0

850W 80 PLUS (GOLD)

4
